function varargout = GUI_TEST(varargin)
% GUI_TEST MATLAB code for GUI_TEST.fig
% GUI_TEST, by itself, creates a new GUI_TEST or raises the existing
% singleton*.
%
% H = GUI_TEST returns the handle to a new GUI_TEST or the handle to
% the existing singleton*.
%
% GUI_TEST('CALLBACK',hObject,eventData,handles,...) calls the local
% function named CALLBACK in GUI_TEST.M with the given input arguments.
%
% GUI_TEST('Property','Value',...) creates a new GUI_TEST or raises the
% existing singleton*. Starting from the left, property value pairs are
% applied to the GUI before GUI_TEST_OpeningFcn gets called. An
% unrecognized property name or invalid value makes property application
% stop. All inputs are passed to GUI_TEST_OpeningFcn via varargin.
%
% *See GUI Options on GUIDE's Tools menu. Choose "GUI allows only one
% instance to run (singleton)".
%
% See also: GUIDE, GUIDATA, GUIHANDLES
% Edit the above text to modify the response to help GUI_TEST
% Last Modified by GUIDE v2.5 20-Mar-2020 09:03:44
% Begin initialization code - DO NOT EDIT
gui_Singleton = 1;
gui_State = struct('gui_Name', mfilename, ...
'gui_Singleton', gui_Singleton, ...
'gui_OpeningFcn', @GUI_TEST_OpeningFcn, ...
'gui_OutputFcn', @GUI_TEST_OutputFcn, ...
'gui_LayoutFcn', [] , ...
'gui_Callback', []);
if nargin && ischar(varargin{1})
gui_State.gui_Callback = str2func(varargin{1});
end
if nargout
[varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
else
gui_mainfcn(gui_State, varargin{:});
end
% End initialization code - DO NOT EDIT
% --- Executes just before GUI_TEST is made visible.
function GUI_TEST_OpeningFcn(hObject, eventdata, handles, varargin)
% This function has no output args, see OutputFcn.
% hObject handle to figure
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% varargin command line arguments to GUI_TEST (see VARARGIN)
% Choose default command line output for GUI_TEST
handles.output = hObject;
% Update handles structure
guidata(hObject, handles);
% UIWAIT makes GUI_TEST wait for user response (see UIRESUME)
% uiwait(handles.figure1);
global label;
label=0;
% --- Outputs from this function are returned to the command line.
function varargout = GUI_TEST_OutputFcn(hObject, eventdata, handles)
% varargout cell array for returning output args (see VARARGOUT);
% hObject handle to figure
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
% Get default command line output from handles structure
varargout{1} = handles.output;
% --- Executes on button press in pushbutton1.
function pushbutton1_Callback(hObject, eventdata, handles)
% hObject handle to pushbutton1 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
global OriginalPic;
[filename,pathname]=uigetfile({'*.bmp;*.jpg;*.png;*.jpeg;*.tif'},'选择一个图片','F:\test');
str=[pathname filename];
if isequal(filename,0)||isequal(pathname,0)
warndlg('Please select a picture first!','Warning');
return;
else
OriginalPic= imread(str);
axes(handles.axes1);
imshow(OriginalPic);
end;
% --- Executes on button press in pushbutton5.
function pushbutton5_Callback(hObject, eventdata, handles)
% hObject handle to pushbutton5 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
global OriginalPic;
global GrayPic;
global label;
[rows , cols , colors] = size(OriginalPic); %原图的矩阵参数
GrayPic = zeros(rows , cols); %用参数创建一个全零矩阵，来存储用灰度图像
GrayPic = uint8(GrayPic);%图像是double型的，将全零矩阵转化为uint8格式
for i = 1:rows
for j = 1:cols
GrayPic(i , j) = OriginalPic(i , j , 1)*0.3+OriginalPic(i , j , 2)*0.59+OriginalPic(i , j , 3)*0.11;
%按照W=0.30,V=0.59,U=0.11进行加权运算，得到最合理的灰度图像
end
end
axes(handles.axes2);
imshow(GrayPic);
label=1;
% --- Executes on button press in pushbutton6.
function pushbutton6_Callback(hObject, eventdata, handles)
% hObject handle to pushbutton6 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
global OriginalPic;
global ScalePic;
global label;
ScalePic=imresize(OriginalPic,0.5,'cubic');
axes(handles.axes2);
imshow(ScalePic);
label=2;
% --- Executes on button press in pushbutton7.
function pushbutton7_Callback(hObject, eventdata, handles)
% hObject handle to pushbutton7 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
global OriginalPic;
global GrayPic;
global ScalePic;
global label;
[FileName,PathName] = uiputfile({'*.jpg','JPEG(*.jpg)';...
'*.bmp','Bitmap(*.bmp)';...
'*.gif','GIF(*.gif)';...
'*.*', 'All Files (*.*)'},...
'Save Picture','Untitled');
if FileName==0
return;
else
if(label==1)
imwrite(GrayPic,[PathName,FileName]);
else if(label==2)
imwrite(ScalePic,[PathName,FileName]);
else
imwrite(OriginalPic,[PathName,FileName]);
end
end
end
% --- Executes during object creation, after setting all properties.
function axes1_CreateFcn(hObject, eventdata, handles)
set( gca, 'xtick', [] ); %去掉x轴的刻度
set( gca, 'ytick', [] ); %去掉y轴的刻度
% hObject handle to axes1 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles empty - handles not created until after all CreateFcns called
% Hint: place code in OpeningFcn to populate axes1
% --- Executes during object creation, after setting all properties.
function axes2_CreateFcn(hObject, eventdata, handles)
set( gca, 'xtick', [] ); %去掉x轴的刻度
set( gca, 'ytick', [] ); %去掉y轴的刻度
% hObject handle to axes2 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles empty - handles not created until after all CreateFcns called
% Hint: place code in OpeningFcn to populate axes2
% --- Executes on key press with focus on pushbutton1 and none of its controls.
function pushbutton1_KeyPressFcn(hObject, eventdata, handles)
% hObject handle to pushbutton1 (see GCBO)
% eventdata structure with the following fields (see MATLAB.UI.CONTROL.UICONTROL)
%Key: name of the key that was pressed, in lower case
%Character: character interpretation of the key(s) that was pressed
%Modifier: name(s) of the modifier key(s) (i.e., control, shift) pressed
% handles structure with handles and user data (see GUIDATA)
% --- If Enable == 'on', executes on mouse press in 5 pixel border.
% --- Otherwise, executes on mouse press in 5 pixel border or over pushbutton1.
function pushbutton1_ButtonDownFcn(hObject, eventdata, handles)
% hObject handle to pushbutton1 (see GCBO)
% eventdata reserved - to be defined in a future version of MATLAB
% handles structure with handles and user data (see GUIDATA)
